Toggle Type Horizontal Clamping Vertical Injection Moulding Machine

  1. Clamping Force : 30 tons to 70 tons
  2. Oil Reservoir Capacity : 60 litres to 180 litres
  3. Fully Microprocessor Controller
  4. Auto Lubricating System
  5. 5 Point Toggle Clamping Design
  6. Vertical Screw Type Injection
  7. Programmable Speed & Pressure Control

Finished Product

Show more
Show less
  • High pressure & with low noise fixed vane pump.
  • Pressure & flow controlled by proportional valve.
  • Horizontal mould clamping thought high performance V type toggle.
  • High performance mould clamping structure.
  • Suitable for all type’s of mold from small to big size.
  • Sliding clamp vice for mould runner & nozzle hole centre.
  • Hard chrome plated steel tie-bars.
  • Mould clamp pressure & speed controlled by HMI thought linear scale.
  • Mould clamp function up to 4 stage (slow fast slow tonnage).
  • Vertical screw type injection thought high pressure hydraulic cylinder.
  • Injection pressure & speed controlled by HMI thought linear scale.
  • Injection unit manually up-down for mould height settings.
  • Suck back after or before refiling.
  • Large L/D ratio for optimum melts.
  • Screw circumferential speed display.
  • Proven screw geometry for optimum melts homogeneity.
  • Wear & corrosion resistance plasma nitrated screw & barrel.
  • Material barrel designed for mould all kind of plastic raw materials.
  • Center hydraulic ejector.
  • Hydraulic ejector pressure & speed controlled by HMI.
  • Best design for long inserts moulding.
  • Safe, Reliable, Very easy operate machine.
  • Silent & power saving hydraulic power pack.
  • Close tank, suction line & return line filteration.
  • Contractor operated four zone digital temperature controllers.
  • Machine can be operate (1) Manual (2) Semi (3) Fully Auto
  • Electric motor starter with over load relay.
  • Flash proof & power saving moulding.
  • Save material processing charges.
  • Fastest cycle time for get mass production.
Model Unit ABST 60 ABST 100 ABST 150 ABST 200 ABST 300 ABST 500
Injection System
Screw Diameter mm 25 30 30 35 35 40 35 40 35 40 50
Injection Pressure kg/cm2 1119 777 1146 842 1165 892 1165 892 1165 892 965
Theoretical Shot Volume cm3 49 71 95 130 155 207 202 263 298 389 638
Max. Shot Weight (PS) gm 30 60 60 100 100 150 150 200 200 300 500
Screw Speed (Max) rpm 0-200 0-200 0-200 0-200 0-200 0-200
No. of Temperature Control zone 4 4 4 4 4 5
Clamping System
Material Hopper Capacity liters 8 10 10 20 20 30
Clamping Force Tons 30 40 50 60 60 70
Opening Force Tons 7.5 8.3 10 13 13 13
Max. Mold Size (LxW) mm 240 x 240 260 x 280 280 x 280 340x340 340 x 340 340 x 400
Opening Stroke mm 165 210 290 320 320 430
Min. MoId Height mm 250 260 295 350 350 400
Max. MoId Height mm 75 130 130 135 135 233
Max. Open Daylight mm 415 470 585 670 670 830
Ejector Force Tons 1.3 1.3 1.3 2 2 2
Ejector Stroke mm 50 70 70 70 70 70
Hydraulic & Electric Systems
Max. Hydraulic Pressure kg/cm2 140 140 140 140 140 140
Oil Reservoir Capacity liters 60 80 100 140 140 180
Pump Motor kW 2.2 3.5 3.5 5 5 8.8
Barrel Heating Power kW 3.2 4 5 6.1 6.1 8.3
Total Wattage kW 5.4 7.5 8.5 11.1 11.1 17.1
Machine Weight Tons 1 1.2 1.5 1.8 1.9 2.24
Machine Dimensions (LxWxH) m 1.8x1x2.6 2x1.1x2.8 2x1.1 x2.9 2.4x1.2x3 2.4x1.2x3 2.6x1.2x3.7
